ELECTRICAL SYSTEM
6. For installation, reverse order of
1. Operating from fender inside,
(3) For installation of transparent
remova I. compress the two springs securing
cover,reverse order of removal.
transparent cover of side direction
LAMP REPLACEMENT indicator @ to fender@, then
CAUTION: remove it.
Do not touch with the hands glass of
Headlights and front side lights 2. Withdraw lampholder@ from
headlight halogen lamp2 . If thisdirection indicator 1_
0
1. Operating from engine com-
occurs, wash the glass. 3. Replace lamp@ by pulling
partment inside, rotate cover
0 the relevant bulb.
clockwise, then remove it. 4. Install direction indicator by
Front direction indicators
reversing order of removal.
1. Operating from engine com-
partment inside, rotate lamp- SETTING OF HEADLIGHTS
counterclockwise, then
holder @ LOW BEAM
remove it. Carry out the following procedure to
2. Press lamp bulb@ and rotate
adjust headlight low beam.
it in order to withdraw lamp.
1. Check that tires are inflated at
3. Replace the lamp and install
lampholder 0. the right pressure and that car is free
from any load excepted those of
service supplies and of one passenger
equivalent.
2. Position the car and the possible
test equipment on an horizontal
1 Cover plane. If no test equipment isavail-
front of a clear
able, place the car in
screen.
2. Disconnect SuPPlY con-
nector 0. of aboutIO m
3. Rotate securing spring@ 3. Move car back
on lowbeams.
counterclockwise,and remove it. (32,8 ft) and switch
The luminous beam must be in
4. Withdraw halogen lamp@ and 1 Lamp 2 Lampholder
replace it. On reassembly, replace the compliance with geometric dimen-
Side direction indicators sions provided in figure.
lamp, make sure the cover is properly
positioned by correct alignment
of the notches.
5. To remove headlight lamp@,
withdraw lampholder0, press bulb
and rotate it counterclockwise.
1 Side direction indicator
2 Lamp
3 Lampholder
4 Fender
1 Supply connector
2 Halogen lamp
3 Securing spring
4 Lamp
5 Lampholder
May 1983 40-18
