text version of content this owner's manual page from owners manual to the vehicle Nissan Skyline, year of production 1998 - 2002:

ANTI-LOCK BRAKE SYSTEM Control Unit InputfOutput Signal Specifications (Cont'd) USING CONSULT Indicated are the control unit computed data. If the output circuit (harness) should be open or short- circuited, correct values may be displayed. Display Monitor item Data monitor Check item (Reference) Condition Specifications FR RH SENSOR Vehicle is stationary. I 0 kdh FR LH SENSOR Wheel speed Virtually the same speed Wheel sensor and circuit RR SENSOR [kdh] Vehicle is drivem'l as speedometer (within +I 0%) Brake pedal is STOP LAMP SW Brake pedal status depressed. Stop lamp switch and [ON-OFF] Brake pedal is not OFF circuit depressed. -- -- Actuator (solenoid) is FR RH IN SOL activated (at CONSULT FR LH IN SOL active test), REAR IN SOL or actuator relay is not [ON-OFF] activated (with fail-safe Solenoid status function activated and ABS solenoid and circuit engine not running). -- -- - -- - FR RH OUT SOL Actuator (solenoid) is not FR LH OUT SOL activated and actuator REAR OUT SOL relay is activated (with OFF [ON-OFF] vehicle stopped and engine running). Actuator relay is acti- vated (with engine run- ON ACTUATOR RLY ning). ABS actuator relay and [ON-OFF] Actuator relay status Actuator relay is not acti- circuit vated (with fail-safe OFF function activated and engine not running). Motor relay and motor MOTOR RLY Motor relay and motor are activated (at CON- ABS motor, motor relay, [ON-OFF] status SULT active test). and circuit Motor relay and motor OFF are not activated. - - WARNING LAMP ABS warning lamp sta- Waming lamp ON'2 1 ON ABS warning lamp and [ON-OFF] tus -- - circuit Warning lamp OFF'2 1 OFF - - Control unit power sup- BAlTERY VOLT [V] Power supply voltage Ignition switch ON provided for control unit ply circuit '1: Tire pressure must be in accordance with specification. "2: ABS warning lamp ON: When the ignition switch is turned ON (before starting the engine) or a malfunction is detected ABS warning lamp OFF: One second after the ignition switch is turned ON (with the system in normal condition)
