ENGINE COOLING SYSTEM
SERVICE DATA AND SPECIFICATIONS
ELECTRIC FAN
INSPECTION AND
ADJUSTMENT Electric fan intervention CAUTION:
temperature 88 - 92°C Produit harmful to the paint. Avoid
(190.4+ 197.6”F) contact with painted parts.
BELT TENSIONING
Load to be applied:78.4 N COOLING SYSTEM SCALES
(8 kg REMOVER
17.64 lb) GENERAL
Resultant arrow mm NALCO: 1006
SPECIFICATIONS
INTERPOIND: Auto Cat.
105.6 in) Jal
3681-69955
THERMOSTAT COOLANT
TEMPERATURE Summer
84 + 88°C
- Start of opening
(183.2 + 190.4”F) Water I 7.3
- End of opening986 Imp. Gall 1.61
(2084°F) Winter
- Bulb travel>7 Min. tempera-
(> 0.28:; -35
tu re T -10 -20
RADIATOR OF (14) i-4)1-31I
Radiator leak control Antifreeze cat.
3.65
3661-69956 2.6 I
pressure 107.9 kPa 1.8
(1.0 bar; (Imp. gall)(0.391 (0.57:10.80)
1 .I kg/cm2; Water I 5.5 4.7 3.65
15.64 psi) (Imp. gall)(I .2) (I .03IO.801
PRESSURIZED PLUG Antifreeze ready
for use cat.
-
3681-69958 I
Pressurized @lug setting 7.3
(Imp. gall)-
pressure 68.6 kPa (1.61
(0.69 bar;
0.7 kg/cm’;
9.95 Psi)
SEALING AND FIXING COMPOUNDS
Application TYW Denomination Q.W
Sealing compound for cooling&tern Sealing powderAREXONS Cat.3522-00101 7.3 g
0.20 (az)
ALUMASEAL can be used as an alternative.
Of-7 May 1983
