PDe Euro spain 7.qxp 22.11.2016 9:46 Page 61
Panel de fusible del compartimiento del motor
■ Kappa 1,4 MPI
Número Nombre del Símbolo Amperaje Circuito protegido
fusible del fusible
F48 TCU 2 T2 15A Bloque de xiones coneE/R le:(FusibF34)
F49 SENSOR 3 S3 10A Bloque de xiones coneE/R (RELÉ 7)
F50 ECU 4 E4 15A -
F51 WIPER 25A Relé de limpiaparabrisas
Mantenimiento
F52 HORN 15A Relé de la bocina
■ Gamma 1,6 MPI
Número Nombre del Symbolo Amperaje Circuito protegido
fusible del fusible
S2 Sensor de posición del árbol de levas 1/2, válvula solenoide de control de purga,
F37 SENSOR 2 10A válvula de control de aceite 1/2, válvula solenoide de entrada variable, bloque de
7
xiones coneE/R (RELÉ 1, RELÉ 2)
F38 ECU 2 E2 10A ECM/PCM
F39 ECU 1 E1 20A ECM/PCM
F40 INJECTOR INJECTOR 15A Inyector n°1/2/3/4
F41 SENSOR 1 S1 15A Sensor de xígeno o(arriba), sensor de xígeno o(abajo)
7-61
