text version of content this owner's manual page from owners manual to the vehicle Mitsubishi Eclipse, year of production 1995 - 1999:

INTERIOR - Seat 6-7 Worm aear B Slide adjustment switcl POWER SEAT N76ZDOlAA -.-----a--- Slide Adjustment Structure Limit .ywq The motor, limit switch and gears are mounted on the plate fixed to the lower rails. When the slide adjustment switch is operated, the motor starts and rotates worm gear A in the gear box via the cable wire. Lower rail This rotating torque is transmitted through gears A and B to worm gear B. The worm gear B moves the upper rails and therefore the seat mounted on the upper rails. - When the seat slides to the forward or backward limit, the Cable wire 19X0668 cover mounted to the upper rail pushes the limit switch and turns the motor off. This stops the seat slide operation. Front Height and Rear Height Adjusting Structure The front and rear portions of the seat cushion can As the seat cushion continues to rise, the claw on be raised and lowered independently. If the frontthe shaft turns the limit switch from ON to OFF, height and rear height switch is pushed to the upcutting off power to the motor and stopping it. side, motor revolutions will be transferred to gearIn addition, if the front height and rear height switch to sector gear. Since the sector gear, shaft and armis pushed to the down side, operation is reversed are fixed, the seat cushion rises continuously(step- with the motor revolving in the opposite direction less) along with the revolution of the sector gear.and lowering the seat cushion. Sector gear Rear height motor a Arm\ Front height motor When raising front height When raising rear height /!&.=I When raisiyg front and rear height : cushion 19FOO49 Seat cushion / Seat yshion ,.f-----. Power seat switch‘+“. , Power seat switch Limit switch Limit switch Arm 19X0673
