text version of content this owner's manual page from owners manual to the vehicle Alfa Romeo 33, year of production 1983 - 1995:

REAR SUSPENSION DATA FOR SHOCK ABSORBER CALIBRATION Alfa Romeo Part Number 542.147 Compression N (kg) (lb) 59 f 147(6+ 15)(13.23G33.07) Low speed Extension N (kg) (ib) 78+ 177(8e-18) (17X4+39.68) Compression N kg) (lb) 275 f 412(28+42) (61.73G92.59) High speed Extension N (kg) (lb) 638 f 834 (65 + 85) (14XW87.39) NOTE: Values to be measured with shock absorbersat 20 L PC (68 f 3.BF) temperature TIGHTENING TORQUES Item N-m kg-m Ib+t Bolts securing Panhard bar to body 68.67 + 86.35 7 + 8.7 50.63 + 62.93 33.35 + 38.26 3.4+ 3.9 24.58 + 28.2 Bolts securing front and rear tie rods to body Bolts securing stem pin to axle 39.24 + 48.1 4 + 4.9 29.92 + 35.43 7.85 + 9.8 0.8 + 1 5.78 + 7.23 Brake hydraulic system rigid tube connections 9.8 + 14.7 1 + 1.5 7.23 + 10.85 Brake hydraulic system flexible hose connections_. TROUBLE DIAGNOSIS AND CORRECTIONS When rear suspensions are suspected of being noisy, carry out a careful check to determine if the noise actually originates in the rear suspensions or if it is due to the tires, road surface, exhaust system, engine, transaxle or wheel bearings. Condition Probable cause Corrective action Noise Loose wheel screws Tighten to specified torque One or more attaching bolts loosenTighten to specified torque Lack of lubricating grease on Lubricate as required bearings Faulty shock absorber Replace Damaged or worn wheel bearingReplace Wheel and tire out-of-balanceBalance Damage to rubber parts such as Replace damaged parts lower arm bushing May 1983 25-10
