CUTIE DE VITEZE, AMBREIAJ ªI DIFERENÞIAL ( CUTIA DE VITEZE ) 8A–25 3 Alegeþi ºaiba distanþier în aºa fel încât jocul A sã fie conform standardului. (mm) Valori mãsurate Grosime ºaibã 0.33 – 0.37 0.45 0.38 – 0.42 0.50 0.43 – 0.47 0.55 0.48 – 0.52 0.60 0.53 – 0.57 0.65 0.58 – 0.62 0.70 0.63 – 0.67 0.75 0.68 – 0.72 0.80 FIG. 8A – 60 MONTARE CAPAC CARCASà 0.73 – 0.77 0.85 0.78 – 0.82 0.90 • Asamblaþi manºonul ºi butucul sincronizatorului 0.83 – 0.87 0.95 treptei a 5-a, ca în figurã. 0.88 – 0.92 1.00 1. ARC SINCRONIZATOR 0.93 – 0.97 1.05 TREAPTA A 5-A 2. PASTILà 0.98 – 1.02 1.10 3. BUTUC 2 F 4. MANºON 1.03 – 1.07 1.15 BALADOR D 2 1 4 C B E 3 3 1 A = B A C: INTERIOR ARC A D: BUTUC ROATà E: LOCAº ZÃVOR F: CANELURI INTERIOARE 4 FIG. 8A – 61 ASAMBLARE MANªON ªI BUTUC TREAPTA A 5-A • Pinionul treptei a 5-a va fi montat cu suprafaþa prelucratã a butucului conducãtor în interior. 1. LINIE DREAPTà 1 2. ARBORE SECUNDAR 3. RULMENT 3 4. ªAIBà DISTANÞIER 5. REPER 5 2 FIG. 8A – 59 ALEGERE GROSIME ªAIBà DISTANÞIER • Dupã ce aplicaþi loctit pe suprafaþa de prindere a carcasei, strângeþi la valoarea specificatã. 1. PINION TREAPTA A 5-A Cuplu de strângere pentru 60 – 70 2. BUTUC CONDUCÃTOR capac carcasã 3. BUTUC CONDUS FIG. 8A – 62 PINION TREAPTA A 5-A
