Electrical controls on the driver and front passenger seats
Fig. 57 Driver seat: controls to adjust lumbar support 1, seat cushion 2, and seat backrest angle 3.
¤ Please first read and note the introductory information and heed the WARNINGS .
The controls on the front passenger seat mirror those on the driver seat.
There may be manual and electrical controls on the same seat.
⇒ fig. 57 Press or move the control in the direction of the arrow or in the area shown.
(1) Adjust lumbar support by pressing in the a(A)rea o r (B).
(2) Slide the seat backward or forward by pushing in the direction of ar(1ro)w.
Raise or lower the seat cushion by pushing in the direction of arrow (2).
(3) Adjust backrest angle by pushing forward or backward in the direction of the arrow.
WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has
been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key
in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the unsu-
pervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjustedor ,
while calling up the stored memory settings for the front seats. In an emergency, stop auto-
matic seat adjustment by pressing a seat adjustment switch.
NOTICE
To help prevent damage to electrical parts in the seat, do not kneel on the front seats or apply
concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
