x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlck o
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling settings for driver seat and outside mirrors
x Briefly press the appropriate memory button when the vehicle is not moving, the ignition is
switched off, and the driver door is open.
x OR: If the ignition is switched on and the driver door is closed, press and hold the appropriate
memory button until the stored position is reached.
x The passenger-side outside mirror automatically adjusts back from the position storedor f backing
up when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is
rotated from R into a different position.
Assigning driver seat and outside mirror settings to a vehicle key
The memory function of all vehicle keys is disabled when the vehicle is first delivered from the factory.
To enable vehicle key memory function:
x Unlock the driver door.
x Press and hold a memory button until memory position is reached.
x Press and hold the unlock butto0non the vehicle key and then press the desired memory button at
the same time within about 3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
x Press and hold the SET button.
x Press and hold the unlock button0 on the vehicle key and the desired memory button at the same
time within about 10 seconds. A chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
x Follow the instruction⇒ s page 120 to assign the driver seat and outside mirror settings to the
vehicle key.
x Unlock the vehicle with the same vehicle key.
x Adjust driver seat and outside mirrors.
x Lock the vehicle with locking button1 in the vehicle key to store the settings.
Once the settings are stored, the driver seat and the outside mirrors move to the stored positions
whenever the vehicle is unlocked with the vehicle key open button 0 and the driver door is opened. If
two people use the vehicle, each of them should always use the key in which his or her personal
settings have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop in certain situations, for instance, if a new
driver seat is installed.
Initializing clears all memories and assignments of the memory seat. After that, memory buttons can
be reprogrammed and assigned to a vehicle key.
x Open the driver door but do not enter the vehicle.
x Adjust the seats from the outside.
x Move the angle of the backrest forward as far as it will go.
x Release the backrest adjustment switch and press it again until you hear a chime sound.
Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x The vehicle battery is weak or dead.
