Fig. 51 To program: Simultaneously press the buttons for the HomeLink Universal Transmitter and the remote
control.
¤ Please first read and note the introductory information and heed the WARNINGS .
Getting ready to program
d Please read the product manufacturer's instructionsbe fore programming the garage door opener
or other device.
d Safely park the vehicle within range of the device to be programmed.
d Switch the ignition on, but do not start the engine.
The buttons 1, 2, and 3 on the keypad in the sun visor can operate up to 3 separate devices (for
example, a gate and garage door, house alarm or lighting system).
Please carry out each step only in the order specified:
1. For first time programming only: Press and hold the two outer HomeLink buttons 1 and
3 at the same time for about 20 seconds, releasing only when the HomeLink indicator light
above button 2 begins to flash.
This step deletes any old settings. Do not perform this step when programming the
additional HomeLink buttons.
2. Position the hand-held transmitter for your remote control device 1-3 inches (25-75 ) mm
away from the HomeLink keypad on the driver side sun visor, keeping the HomeLink indi-
cator light in view, as shown ⇒ fig. 50.
3. Using both hands, simultaneously press and hold both the HomeLink button you want to
program (1, 2, or 3) and the hand-held transmitter button, as shown ⇒
fig. 51. Do not
release the buttons until the HomeLink indicator light flashes slowly and then rapid-
ly. When the indicator light flashes rapidly, release both buttons. The rapid flashing indi-
cates successful programming.
Press and hold the programmed HomeLink button and watch the indicator light.
If the indicator light comes on and does not flash, programming is complete and your
garage door opener or other device should activate when the HomeLink button is pressed
and released.
4. If the indicator light blinks rapidly for 2 seconds and then stays on, proceed with the follow-
ing programming instructions for a rolling code device. A second person may make the
following steps quicker and easier. Please use a ladder or other device. Do not stand on
your vehicle to perform the next steps ⇒ .
