text version of content this owner's manual page from owners manual to the vehicle Alfa Romeo 147 GTA, year of production 2000 - 2010:

A0A0205m FAN SPEED ADJUSTMENT KNOB (fig. 82-83) Turning the ring of knob (4), clockwise or counter-clockwise, increases or decreas- es the speed of the fan, thus the amount of air admitted to the passenger compart- ment; the 16 selectable speeds are shown on a bar (in steps of 3) up to a maximum of 6 bars lit: - maximum fan speed = all bars lit; - minimum fan speed = one bar lit. The fan can be cut off (all bars off) only fig. 82 A0A0206m if the climate control compressor has been GETTING TO KNOW YOUR CAR switched off pressing button (14) √. To restore automatic fan speed control, after a manual adjustment, press button (13) AUTO. Completely turning the ring of knob (4) counter-clockwise switches the system off, with the following situation: display (1) off; display (5) off; centre display (3) with lit displayOFF and left led on inside air re-cir- culation button (8) von. IMPORTANT Pressing the inside air re- circulation button (8) vit is possible to obtain the inlet of untreated outside air to the passenger compartment. fig. 83 To turn the system on again, simply turn tion (8) and rearscreen heating (9) but- IMPORTANT On leaving the OFF condi- the ring of knob (4) clockwise, or press any tons; this operation restores all the operating tion, inside air re-circulation vreturns to one button, except the inside air re-circula- conditions stored previously. the condition prior to switching off. 99
