text version of content this owner's manual page from owners manual to the vehicle Mitsubishi Eclipse, year of production 1995 - 1999:

ENGINE - Cooling System COOLING SYSTEM N710mmM l The cooling fan control has been integrated The cooling system is of the water-cooled, forced icirculation type with the following features: into the centralized control by the engine control module for better cooling efficiency, better fuel l A small-size, high-performance radiator has consumption, less noise, and better accelera- been adopted for better cooling efficiency and less weight. tion. (For detailed information on the controls, refer to P.l-76.) l Reduction in size of the automatic transaxle l The system uses an “inlet coolant temperature oil cooler had resulted in a lowered radiatormethod” which is achieved by locating the ther- position, which has permitted the “slant nose” mostat at the coolant inlet side of the engine. design of the body. COOLANT FLOW When engine is cold (Thermostat closed): Cylinder head Throttle body I 1 Water inlet pipe k Heater Thermostat case 1-I 1 (Thermostat) 1 Turbocharger When engine is hot (Thermostat open): Cylinder head Throttle body Water inlet pipe Heater Turbocharger i
