506 9-1. Specifications Ignition system (gasoline engine only) Spark plug Make DENSO SC16HR11 Gap 1.1 mm (0.043 in.) NOTICE ■Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust the spark plug gap. Electrical system Battery Specific gravity reading1.250 — 1.290 Fully charged at 20°C (68°F): 1.160 — 1.200 Half charged 1.060 — 1.100 Discharged Charging rates Quick charge15 A max. Slow charge5 A max. Multidrive Fluid capacity* 6.4 L (6.8 qt., 5.6 Imp.qt.) Fluid type Toyota Genuine CVT Fluid FE *: The fluid capacity is the reference quantity. If replacement is necessary, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. NOTICE ■Multidrive fluid type Using Multidrive fluid other than “Toyota Genuine CVT Fluid FE” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. YARIS_F_WE_52F20E
