CX-5_8CA6-EC-11L_Edition1 Page408
Friday, December 9 2011 4:21 PM
Black plate (408,1)
Entretien
Entretien réalisable par le propriétaire
qDescription des panneaux à fusibles
Porte-fusibles (Compartiment moteur)
VALEUR
DESCRIPTION DE COMPOSANTEPROTEGEE
FUSIBLE
1 ADDFANGE 30A Ventilateur de refroidissement
2 IG2 30A Pour la protection de plusieurs circuits
3 INJECTOR 30A Système de commande du moteur
4 FANDE ――
5 P.WINDOW1 30A Lève-vitres électriques
6 ―― ―
7 ADDFANDE ――
8 EVVT 20A Système de commande du moteur
9 DEFOG 40A Dégivreur de lunette arrière
10 DCDCDE ――
11 FANGE 30A Ventilateur de refroidissement
12 ―― ―
13 ―― ―
14 ―― ―
15 ENG.MAIN 40A Système de commande du moteur
16 ABS/DSCM 50A ABS,systèmedecommandedynamiquedestabilité
6-54
Form No.8CA6-EC-11L
