text version of content this owner's manual page from owners manual to the vehicle VW Beetle, year of production 2011:

Color Current strength in ampsCurrent strength in amps (ATO/MINI) (JCASE) Red 10 50 Blue 15 20 Yellow 20 60 White or 25 — clear Green 30 40 Orange 40 — Pink 30 30 Opening the fuse box in the instrument panel x Open the storage compartmen⇒ t fig. 164, Storage areas. x On the back of the cover there are plastic tweezers for removing and inserting fuses. x Press the sides of the storage compartment in slightly(A () arrows) while pulling back firmly ((B) arrow). x Toin stall, guide the cover from the bottom into the instrument panel and push in the direction opposite to the arrows (A), then push forward until you can hear it latch into place. Opening the fuse box in the engine compartment x Open the engine hood , Working in the engine compartment. x Move the release tabs in the direction of the arrow⇒ s fig. 165 to unlock the fuse box cover. x Remove the cover upward. x Toin stall push the cover onto the fuse box. The locking tabs must latch with an audible “click.” NOTICE x To help prevent vehicle damage, be careful when removing fuse box covers and be sure to reinstall them properly. x Open fuse boxes must be protected from dirt and moisture. Dirt and moisture in fuse boxes can cause damage to the electrical system. The vehicle contains other fuses in addition to those mentioned in this section. Have these fuses replaced by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
