from owners manual to the vehicle Porsche Cayenne, year of production 2002 - 2010:
10_Cayenne_21_KW17.book Seite 317 Donnerstag, 9. April 2009 3:33 15
Fuse assignment – fuse box in right side of dashboard
No. Designation Rating in ANo. Designation Rating in A
1 Trailer coupling 15 25 Air conditioner 2+2, rear 5
2 ParkAssist 5 27 Level control, 15
Porsche Dynamic Chassis Control (PDCC)
3 Trailer coupling 15 29 Transmission control unit, Tiptronic selector lever 5
switch
5 Trailer coupling 15 30 Rear lid power closing mechanism relay (control and 20
load)
6 Porsche Stability Management (PSM)3031 Filler flap actuator, rear end control unit (motors)15
7 Transfer box (center-differential lock), telephone prepa-534 Power window and central locking, front right door30
ration
8 Vehicle electrical system control unit (left side marker 3035 Power seat controls, right30
light, right turn signal, right low beam
10 TV tuner, Rear Seat Entertainment10 36 Roof console, electrical compass5
11 Radio or Porsche Communication System (PCM)1038 Porsche Stability Management (PSM)10
12 Amplifier for sound package and Bose3039 Diagnosis 5
14 Tail light, left 15 40 Transfer box (center-differential lock)10
15 Power window and central locking, rear right door3041 Trailer coupling control unit10
18 Heated rear window relay (load)30 42 Roof module 5
19 Trailer coupling, trailer socket connection point2543 Reversing light5
Heatable washer nozzles, chassis switch, seat heating
21 Spare wheel release relay (l oad), horn for alarm system1044 potentiometer, Porsche Dynamic Chassis Control 5
(PDCC)
22 Seat heating, front 25 46 Rear Seat Entertainment 5
23 Air conditioner 2+2 10 48 Level control 10
24 Power seat controls and seat memory, front right3049 Anti-dazzle interior mirror5
Minor Repairs 317
