L8/LF Engines Cooling System
Control
• The cooling fan is controlled according to the engine coolant temperature as follows :
Conditions Duty ratio
° ° 0%
Engine coolant temperature is less than 100 C {212 F}.
° ° 75%
Engine coolant temperature is 106—108 C {223—226 F}.
° ° 100%
Engine coolant temperature is 108 C {226 F} or more.
M5_01T004
• The cooling fan is controlled according to the refrigerant pressure switch condition as
follows:
Conditions Duty ratio
When all of the following conditions are met:
— A/C is on.
— Refrigerant pressure switch (medium pressure) is off.0%
— Vehicle speed is 85 km/h {53 mph} or more.
A/C is off.
When all of the following conditions are met:
— A/C is on. 60%
— Refrigerant pressure switch (medium pressure) is off.
— Vehicle speed is 45—85 km/h {28—52 mph}.
When all of the following conditions are met:
— A/C is on. 65%
— Refrigerant pressure switch (medium pressure) is off.
— Vehicle speed is 45 km/h {27 mph} or less.
When all of the following conditions are met:
— A/C is on. 75%
— Refrigerant pressure switch (medium pressure) is on.
M5_01T005
Service Training Mazda5 01-9
