text version of content this owner's manual page from owners manual to the vehicle Skoda Yeti, year of production 2009:
s5o.1.book Page 243 Monday, April 12, 2010 8:36 AM
Fusibili e lampadine 243
Luci abbaglianti e anabbaglianti Fendinebbia*
Fig. 191 Smontaggio delle lampadine Fig. 192 Smontaggio della lampadina
della luce abbagliante e anabbagliante fendinebbia
– Disinserire l'accensione e tutte le luci. Smontaggio della lampadina fendinebbia
– Girare la calotta di protezione nel senso della freccia OPEN (Apertura) – Disinserire l'accensione e tutte le luci.
pag.242, fig.189 e rimuoverla. – Rimuovere la calotta di protezione di gomma A pag.242, fig. 188.
A
– Rimuovere il connettore A A . – Scollegare il connettore 1 .
A
– Girare la graffa verso il basso A B , finchè si sblocca dalla posizione di fissaggio. – Premendo verso il basso lo zoccolo della lampada estrarre la lampadina difettosa
– Rimuovere la lampadina A C e montarne una nuova prestando attenzione a inse- dal portalampada A 2 e inserirne una nuova.
rire i naselli di fissaggio sull'attacco della lampadina nelle cavità del riflettore. – Introdurre la calotta di protezione.
Per il montaggio procedere in ordine inverso.
Luci diurne
Nota
Si raccomanda, alla sostituzione di una lampadina far controllare la regolazione dei fari
presso un'officina Skoda.
Fig. 193 Smontaggio della lampadina
per luci diurne
Smontaggio della lampadina per luci diurne
– Disinserire l'accensione e tutte le luci.
Uso Sicurezza Consigli di guida Consigli tecnici Panne Dati tecnici
