222 Fuses
FUSESPECIFICATION CHART
Power Distribution Box
WARNING:Always disconnect the battery before servicing high
current fuses.
WARNING:Toreduce risk of electrical shock, always replace the
cover to the power distribution box before reconnecting the
battery or refilling fluid reservoirs.
The power distribution box is located in the engine compartment. It has
high-current fuses that protect your vehicle’s main electrical systems
from overloads.
If the battery has been disconnected and reconnected, see Changing the
Vehicle Battery in the Maintenance chapter.
F19 F8 F7 R15
R16
R9 R6
F31 F30 F24 F21 F20
F37
F15 F13 F11 F9 F42
F25 F22 F17 F38
F32 F43
F27F26 F23 F16 F14 F12 F10 F39
F33 F18 F46
F44
F40
F34 F45
F48F47
R12 F41
F35 F28 R10 R7
F36 F29 R3 R1
R14 R13 R11 R8 R5 R4 R2
2014 Focus (foc)
Owners Guide gf, 1st Printing, October 2012
USA(fus)
