toledo ingles.book Seite 204 Mittwoch, 11. April 2007 1:25 13
204 Accessories, parts replacement and modifications
If a towing bracket is to be fitted after the vehicle is purchased, this must be WARNING (continued)
completed according to the instructions of the towing bracket manufacturer.
The attachment points for the towing bracket A are underneath the vehicle.• If the towing bracket is incorrectly installed, there is serious danger of
A an accident.
The distance between the centre of the ball coupling and the ground should • For your own safety, please observe the instructions provided by the
never be lower than the measurement indicated when the vehicle is fully manufacturer of the towing bracket.
loaded including the maximum resting weight.
Measurement for securing the towing bracket: Caution
B
A65 mm (minimum) • If the electrical socket is incorrectly installed, this could cause damage to
C 350 mm to 420 mm (fully laden vehicle)
A the vehicle's electrical system.
D 344 mm
A
E
A531 mm
F 1,044 mm
A
G 1,040 mm
A
Fitting a towing bracket
• Driving with a trailer implies additional work for the vehicle. Therefore,
before fitting a towing bracket, please contact an Authorised Service Centre
to check whether your cooling system needs modification.
• Observe the legal requirements in your country (e.g. the fitting of a sepa-
rate warning lamp).
• Certain vehicle components, e.g. the rear bumper must be removed and
reinstalled. The towing bracket securing bolts must be tightened using a
torque wrench, and an electrical socket must be used to connect to the
vehicle's electrical system. This requires specialist knowledge and tools.
• The figures in the illustration show the dimensions and attachment points
that must be observed if you are retrofitting a towing bracket.
WARNING
Towing brackets should be fitted by specialists.
