text version of content this owner's manual page from owners manual to the vehicle Hyundai Sonata, year of production 1998 - 2004:

DO-IT-YOURSELF MAINTENANCE 6- 17 G160A01A-AAT G170A02A-AAT G180A01A-AAT CHECKING CLUTCH PEDAL CHECKING BRAKE PEDAL CHECKING BRAKE PEDAL FREE-PLAY FREE-PLAY CLEARANCE 0.24~0.51 in. 0.12~0.31 in. (6~13 mm) (3~8 mm) 2.95 in. (75 mm) G160A01E HXGS508 G180A01L With the engine off, press lightly on the clutchWith the engine off, press down on the brakeYou need a helper to check the brake pedal pedal until you feel a change in resistance. Thispedal several times to reduce the vacuum in theclearance. With the engine running, have your is the clutch pedal free-play. The free-playbrake booster. helper press down on the brake pedal several should be within the limits specified in the illus-Then, using your hand, press down slowly ontimes and then hold it down with a force of about tration. If it is not, have it inspected by yourthe brake pedal until you feel a change in110 lbs (50 kg, 490 N). The brake pedal clear- Hyundai dealer and adjusted or repaired ifresistance. This is the brake pedal free-play.ance is the distance from the top surface of the necessary. The free-play should be within the limits speci-brake pedal to the asphalt sheeting under the fied in the illustration above. If it is not, have itfloor mat. inspected by your Hyundai dealer and adjusted If the brake pedal clearance is not within the or repaired if necessary. limits specified in the illustration, have it in- spected by your Hyundai dealer and adjusted or repaired if necessary.
