Fuse Replacement
MAIN FUSE BOX • Push the storage compartment upwards (holding it against the
pressure of the two springs) while pushing the bottom into
position. Note that the storage compartment pivots near its base
and will latch into place once the two pivot pins have engaged
with the appropriate slots low down on each side of the storage
compartment.
Checking or renewing a fuse
B 9 18 27
A 8 17 26
7 16 25
6 15 24
5 14 23
4 13 22
3 12 21
HB0292B 2 11 20
1 10 19
To access the interior fuse box, first remove the driver's personal
storage compartment as follows (see diagram 'A'):
• Open the storage compartment, then push it upwards (against HB0669
spring pressure) to release it from the retaining pivots (one on 5
each side near the bottom). At the same time, pull the storage Always turn off the starter switch and the appropriate electrical
compartment out and away from the surrounding panel. circuit before removing a fuse. To remove a fuse, press the
removal tweezers onto the head of the fuse and pull. Always
To replace the storage compartment (see diagram 'B'): replace a fuse with another of the same (or lower) rating. If a
• Locate and align the indents at the top (one on each side) of the replacement fuse blows almost immediately, this indicates a serious
storage compartment with the two retaining springs. electrical problem and the circuit MUST be checked by an MG
Rover dealer.
169
