text version of content this owner's manual page from owners manual to the vehicle Alfa Romeo 33, year of production 1983 - 1995:

G EARBOX Shafte, geara and differen~ial caeing @ 220.5 + 245 (22.5 + 25 162.70 + 180.771 QI 69 + 85 (7 + a.7 50.61 + 62.91) 67 + 74 / (6.8 f 7.5 49.17 + 54.23) @ N+m (kg-m ft4b) 1 Direct drive shaft 14 R.G. driven gear 27 3rd speed driven gear 2 Spring 15 Bushing 28 4th speed driven gear 3 Bushing 16 1 st speed driven gear 29 Shim 4 Pin 17 Retainer 30 Bearing 5 Bearing 18 Guide sector 31 5th speed driven gear 6 Reverse gear shaft 19 Locking sector 32 Nut 7 Reverse gear 20 Synchronizing ring 33 Bearing 8 Primary shaft 21 Lock ring 34 Shim 9 longue 22 Sleeve 35 Pinion 10 Bearing 23 HUb 36 Bearing 11 Lock ring 24 Fietainer 37 Differential casing 12 5th speed driving gear 25 2nd speed drive gear 38 Bearing 13 Oil deflector 26 Shouldered ring 39 Crown gear 13-3 May 1983
