text version of content this owner's manual page from owners manual to the vehicle Mazda CX-5, year of production 2012 - 2017:
CX-5_8CA5-EA-11L_Edition3 Page134
Friday, June 22 2012 3:45 PM
Black plate (134,1)
WhenDriving
Instrument Cluster and Display
qSpeedometer Odometer
Thespeedometer indicates the speed of Theodometer records the total distance
the vehicle. the vehicle has been driven.
Trip meter
qOdometer,TripMeterandTrip Thetrip meter can record the total
MeterSelector distance of two trips. One is recorded in
Thedisplay mode can be changed trip meter A, and the other is recorded in
between trip meter A and trip meter B by trip meter B.
pressing the selector while one of them is
displayed. The selected mode will be For instance, trip meter A can record the
displayed. distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.
Whentrip meter A is selected, pressing
the selector again within one second will
Trip meter A change to trip meter B mode.
Odometer Whentrip meter A is selected, TRIPA
will be displayed. When trip meter B is
selected, TRIP B will be displayed.
Press the selector
Thetrip meter records the total distance
the vehicle is driven until the meter is
Trip meter B again reset. Return it to “0.0” by holding
Odometer the selector depressed for 1 second or
more. Use this meter to measure trip
distances and to compute fuel
consumption.
Press the selector
NOTE
l Only the trip meters record tenths of
kilometers (miles).
NOTE l Thetrip record will be erased when:
Whentheignition is switched to ACC or OFF, l The power supply is interrupted (blown
the odometer or trip meters cannot be fuse or the battery is disconnected).
displayed, however, pressing the selector l The vehicle is driven over 9999.9 km
button can inadvertently switch the trip meters (mile).
or reset them during an approximate ten-
minute period in the following cases:
l After the ignition is switched to OFF from
ON.
l After the driver's door is opened.
4-10
Form No.8CA5-EA-11L
