text version of content this owner's manual page from owners manual to the vehicle Mini Cooper, year of production 1961 - 2000:

ENGINEMANAGEMENTSYSTEM-MEMS ENGINEMANAGEMENTRELAYMODULE CAMSHAFTPOSITION(CMP)SENSOR Service repair no - 18.30.71 Service repair no - 19.22.07 TheenginemanagementrelaymodulecontainstheRemove following relays: Mainrelay WARNING:Theexhaustmanifoldreaches Starter relay very high temperatureswhen the engine is Fuel pump relay runningandcancauseseriousburns. HO2Srelay Allowenginetocoolbeforecommencingwork. Remove 1. Removeaircleaner. See this section. 2. Disconnect multiplug from CMP sensor. 1. Release relay module from mounting bracket.3. Removebolt(8mm)securingCMPsensorto 2. Disconnect 2 multiplugs from relay module.cylinder block. 3. Removerelaymodule. 4. RemoveCMPsensor. 5. Remove’O’ring from CMP sensor. Refit Refit 1. Position relay module and connect 2 multiplugs. Ensure multiplugs are correctly1. Clean sealing faces of sensor and cylinder engaged. head. 2. Secure relay module to mounting bracket.2. Lubricate and fit new ’O’ ring to CMP sensor. 3. Fit sensor to cylinder block and tighten bolt to 10Nm. 4. Connect multiplug to CMP sensor. 5. Fit air cleaner. See this section. REPAIRS 13
