text version of content this owner's manual page from owners manual to the vehicle Mitsubishi Eclipse, year of production 1995 - 1999:

POWER TRAIN- Clutch CLUTCH N72ZBWM The clutch is a dry single-disc, diaphragm type; The automatic centering type release bearing has ‘d hydraulic pressure is used for clutch control, been adopted. SPECIFICATIONS Items Non-turbo Turbo Clutch operating method Hydraulic type Clutch disc type Single dry disc type Clutch disc facing diameter O.D. x I.D. mm (in.) 228 x 150 (9.0 x 5.9) 225 x 150 (8.9 x 5.9) Clutch cover type Diaphragm spring strap drive type Clutch cover setting load N (Ibs.) 4,400 (989) 6,174 (1,388) Clutch release cylinder I.D. mm (in.) 22.23 (7/8) 20.64 (13/16)
