from owners manual to the vehicle Fiat Punto, year of production 1999 - 2011:
AUTOMATIC TWO-ZONE CLIMATE CONTROL SYSTEM (DUALZONE)
(where provided) AND
DASHBOARDCONTROLS
DESCRIPTION
The car is fitted with a two-zone climate
control system which makes it possible to SAFETYDEVICES
separately adjust the air temperature on the
drivers side and on the passengers side.
CONTROLS CORRECT USEOF THE CAR
(A): Air distribution selection button
(B): Display showing climate control system
data ARNING
W LIGHTS ANDMESSAGES
(C):Passenger compartment temperature
sensor
(D):MAX-DEF function button (front window IN AN
fast defrosting/demisting) F0I0053m EMERGENCY
(E): Air recirculation on/off button (H):Knobs for adjusting fan speed
(F): Button for aligning the temperature set (I):Climate control compressor on/off button CAR
on the passengers side with that on the (L): Button for selecting the system automatic mode (AUTO) and MAINTENANCE
drivers side (MONO) and knob to adjust knob to adjust temperature on driver side
temperature on passenger side TIONS
(G):Two-zone climate control on/off button TECHNICAL
SPECIFICA
INDEX
71
