text version of content this owner's manual page from owners manual to the vehicle Mercedes CL, year of production 2006:

Technical data Engine Engine 1 1 Model CL 550 (216.371) CL 600 (216.376) Engine 273 275 Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection No. of cylinders 8 12 Bore 3.86 in (98.00 mm) 3.23 in (82.00 mm) Stroke 3.56 in (90.50 mm) 3.43 in (87.00 mm) 3 3 Total piston displacement 333.3 cu in (5461 cm ) 336.4 cu in (5513 cm ) Compression ratio 10.7:1 9:1 Output acc. to SAE J 13492 382 hp/6000 rpm 510hp/5000rpm (285 kW/6000 rpm) (380 kW/5000rpm) Maximum torque 391lb-ft/3000 rpm 612lb-ft/1800 - 3500 rpm acc. to SAE J 1349 (530Nm/3000rpm) (830 Nm/1800-3500rpm) Maximum engine speed 6500rpm 5750rpm Firing order 1-5-4-2-6-3-7-8 1-12-5-8-3-10-6-7-2-11-4-9 Poly-V-belt 2404mm 2370mm 1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. 2 Premium fuel required. Performance may vary with fuel octane rating. 677
