text version of content this owner's manual page from owners manual to the vehicle Nissan Skyline, year of production 1998 - 2002:

TROUBLE DIAGNOSES Shift Schedule VEHICLE SPEED WHEN SHIFTING GEARS RB20DE engine (4AX03 model) Throttle opening I Shift pattern 1 Vehicle meed km/h D14D2 I D2*D3 I D34D4 1 D4-1D3 I D3*D2 I D24D1 Full throttle Normal 46 - 50 91 - 99 149 - 159 144 - 154 86 - 94 41 - 45 Power 46 - 50 91 - 99 149 - 159 144 - 154 86 - 94 41 - 45 Half throttle Normal 31 - 35 62 - 68 101 - 109 71 - 79 41 - 45 6-10 Power 43 - 47 84 - 90 135 - 143 83 - 91 45 - 51 6- 10 RB25DE engine (4AX01 model) I I Vehicle s~eed km/h Throttle opening Shift pattern I D2-rD3 I DJdD4 I D4*D3 1 D3*02 1 D24D1 I Full throttle Normal 50 - 54 101 - 109 157 - 167 151 - 161 96 - 104 40 - 44 Power 50 - 54 101 - 109 157 - 167 151 - 161 96 - 104 40 - 44 I Half throttle Normal 32 - 36 61 - 67 104 - 112 80 - 88 37 - 43 6-10 Power 42 - 46 85 - 91 135 - 143 87 - 95 45 - 51 6-10 RB25DET engine (4AX00 model) Throttle opening Shift pattern Vehicle speed krnlh D14D2 I D2*D3 I D3*D4 I D4*D3 I D3*DZ I D2+D1 - - -- -- - -- -- Full throttle Normal 45 - 49 103 - 111 167 - 177 161 - 171 98 - 106 40 - 44 Power 45 - 49 103 - 111 167 - 177 161 - 171 98 - 106 40 - 44 Half throttle Normal 31 - 35 74 - 80 111 - 119 63 - 71 32 - 38 6-10 Power 39 - 43 84 - 90 133 - 141 98 - 106 50 - 56 6- 10 VEHICLE SPEED WHEN PERFORMING LOCK-UP Engine type RB20DE RB25DE RB25DET Model No. 4AX03 4AX01 4AX00 Closed throttle 31 - 39 34 - 42 - Lock-up ON km/h Half throttle - - - D, speed Closed throttle 23 - 31 25 - 33 59 - 67 Lock-up OFF kmh Half throttle 101 - 109 104 - 112 121 - 129 Lock-up ON km/h Closed throttle 44 - 52 48 - 56 55 - 63 D4 Half throttle 120 - 128 118 - 126 128 - 136 speed Closed throttle 35 - 43 38 - 46 52 - 60 Lock-up OFF kmlh Half throttle 110 - 118 107 - 115 103 - 111 Closed throttle: Throttle opening is 118 or below, and idle switch is turned OFF. Half throttle: Throttle opening is 418.
