text version of content this owner's manual page from owners manual to the vehicle Skoda Fabia, year of production 2007 - 2015:
3ARNING
Removing and installing net partition housing
3hen transporting bicycles, ensuring the safety of the passengers is para-
Fig. ĚĚ mount.
Rear seats: Net partition hous-
ing
CA10ION
Ð
Be careful when maneuvering the bicycle - risk of damage to the vehicle.
Install cross member
Fig. Ěě
First read and observe the introductory information and safety warn-
Install cross member
ings on page Ěĝ.
ä
Removing
› Open the rear right door.
› Fold the seat cushions and rear seat backrests forward – first the left and then
the right backrest.
› Push the net partition housing A » Fig. ĚĚ in the direction of the arrow Ė and
remove it from the mount on the right seat rest in the direction of the arrow ė .
Install
First read and observe the introductory information and safety warn-
› Insert the recesses on the net partition housing into the mounts on the rear
ings on page ěĕ.
ä
seat backrests.
› Push the net partition housing in the opposite direction of the arrow Ė as far
› Remove the rollable luggage compartment cover » page Ěě; if necessary we
as the stop.
recommend you remove the net partition » page ěĕ.
Ð
› Fold the rear seats back into their original position.
› Remove the head rests from the rear seat rests and fold the rear seats for-
ward » page Ěė.
› 1ndo the securing screws C » Fig. Ěě and remove a little to unlock the holders
B .
Bicycle carrier in the luggage compartment
› Place the cross member A with the fixed part onto the left lashing eye and
then place it on the right lashing eye with the removable part of the cross mem-
äIntroduction
ber A .
› Press the holders B until they latch. 0ighten the securing screws C .
0his chapter contains information on the following subjects:
Ð
› Check how well the cross member is fastened by pulling on it.
Install cross member ěĕ
Install bicycle carrier ěĖ
Put bicycle into the bicycle carrier ěĖ
Secure the stability of the bicycles with a belt ěĖ
ěĕ 1sing the system
