EL(FL) GER 7.qxp 2/16/2015 3:49 PM Page 83
Wartung
Nr.Ampere Symbol Bezeichnung Abgesicherter Stromkreis
10 10A AIR BAGSRS-Steuermodul, Leuchte Beifahrerairbag
IPS-Steuergerät (ON/START-Eingang), 4WD-ECM, ICM-Relaiskasten (DBC-Relais),
DBC-Schalter, Kombischalter (Licht), Lenkwinkelsensor, Bremslichtschalter,
11 10A MODULE 1EPS-Steuermodul, Modul Reifenluftdrucküberwachung, Schalter ESC Off,
Sicherungs- & Relaiskasten im Motorraum (RELAIS 8 - ESS), DC/DC-Wandler,
Steuergerät Parkassistent
12 15A HANDLEHTDWickelfeder (Lenkradheizung)
13 10A FOG LP RRICM-Relaiskasten (Nebelschlusslichtrelais)
14 25A WIPER FRTSicherungs- & Relaiskasten im Motorraum (RELAIS 12 - Scheibenwischer langsam),
RELAIS 13 - Scheibenwischer), Scheibenwischermotor, Kombischalter (Wischer)
15 15A S/HEATER FRTKonsolenschalter
16 20A POWER OUTLET 1Zigarettenanzünder und 12V-Steckdose vorn
17 10A BACK-UP LPRückfahrscheinwerfer-Relais
Parkassistentsensor links/rechts, Parkassistentsensor Mitte links/rechts
18 15A DR LOCKTürver- & Entriegelungsrelais, Heckklappenrelais,
ICM-Relaiskasten (Dead-Lock-Relais)
19 7,5A MODULE 2BCM, Smart-Key-Steuermodul, PDM
20 15A WIPER RRICM-Relaiskasten (Heckscheibenwischerrelais), Heckscheibenwischermotor,
Kombischalter (Wischer)
21 15A SUNROOF Schiebedachmotor
783
