alhambra_aleman.book Seite 54 Montag, 23. M‰rz 2009 1:12 13
54 Child safety
Integrated child seat Group 1 integrated child seat
A suitable child seat and a correctly adjusted seat belt can
Basic information on the integrated child seat help to protect your child.
Proper use of child seats substantially reduces the risk of
injury in an accident!
It can be adjusted to suit the child's size and is suitable for children in the
following groups according to the ECE-R 44 norm: Group 1 (9 - 18 Kg), Group
2 (15 - 25 kg) and Group 3 (22 - 36 kg).
The integrated child seat for children in the Groups 1 and 2 must be used
with the slumber roll delivered with the seat.
For safety reasons, we recommend that the child seat for children in Group 1
is installed facing against the direction of travel. To do this, simply remove
the seat and fit it again facing in the opposite direction. The child must be
fastened in using the harness belt. Fig. 35 Using the inte-
grated child seat
The child seat may only be fitted in the direction of travel for children in
Groups 2 and 3 who are fastened in using the three-point belt fitted in the Setting up the child seat
vehicle.
– Pull the loop to the front in the direction of the arrow ⇒ fig. 35
1 .
WARNING A
– Push the seat cushion in direction of the arrow 2 until it
• With the integrated child seat, the backrest may only be adjusted to the A
first or second backrest position for children in Groups 1 to 3.engages in position.
• The slumber roll must always be fitted for children in Groups 1 and 2.3
• The integrated child seat must not be modified in any way.– Pull the loop A to fold down the child seat cushion in direction
4
A
• Do not allow the belt webbing to become twisted or jammed, or to rub of arrow .
on any sharp edges. Restoring the normal seat
• If the child seat or any parts of the seat are damaged, or if the child seat – First fold the child seat cushion up.
has to withstand the force of a collision in an accident, the seat, or part of
the seat, must be replaced - preferably by a qualified dealership.
