Manutenzione e cura
Manutenzione a cura dell'utente
Descrizione pannello fusibili
▼
Scatola fusibili (vano motore)
DESCRIZIONE AMPERAGGIO FUSI- COMPONENTE PROTETTO
BILE
1 C/U IG1 15 A Protezione di vari circuiti
2 ENGINE IG1 7,5 A Sistema di controllo motore
3 SUNROOF 10 A ʊ
4 INTERIOR 15 A Plafoniera
5 7,5 A Sistema di controllo motore
6 AUDIO2 15 A Sistema audio
7 METER1 10 A Quadro strumenti
8 SRS1 7,5 A Airbag
9 METER2 7,5 A *
Quadro strumenti
10 RADIO 7,5 A Sistema audio
11 ENGINE3 15 A Sistema di controllo motore
12 ENGINE1 15 A Sistema di controllo motore
13 ENGINE2 15 A Sistema di controllo motore
14 AUDIO1 25 A Sistema audio
15 A/C MAG 7,5 A Condizionatore d'aria*
*Alcuni modelli. 6-65
