Headlamp low beam (LHD side)
■Based on 10m screen
Maintenance
1 : Vertical line of the left fog lamp bulb center
2 : Horizontal line of fog lamp bulb center
3 : Cut-off line 7
4 : Car axis
5 : W3 (Front fog)
6 : Vertical line of the right fog lamp bulb center
7 : H3 (Front fog)
8 : GROUND OOS077065L
1.Turn the low beam on without driver aboard.
2.The cut-off line should be projected in the cut-off line shown in the picture.
3.When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming.
4. If headlamp leveling device is equipped, adjust the head lamp leveling device switch with 0 positions.
7-71
