Mantenimiento
Descripción Símbolo Amperaje del Circuito protegido
fusible
CLUSTER 10A Tablero de instrumentos, BCM
Módulo de control de bloqueo del cambio ATM, módulo de control EPS,
módulo de control de presión de los neumáticos, retrovisor electrocrómico,
módulo de control SBR, indicador avisador del cinturón de seguridad,
1
IG1 IG1 10A zumbador de ayuda al estacionamiento trasero, interruptor de la luz de freno (Gasolina)
Reostato, sensor de advertencia del filtro de combustible (Diesel),
sensor lateral IZQ/DCH de ayuda al estacionamiento trasero,
sensor central IZQ/DCH de ayuda al estacionamiento trasero
ABS 10A Módulo de control ABS, módulo de control ESC, intettuptor ESC OFF,
caja de relés y fusibles E/R (conector de comprobación multifunción)
B/UP LAMP B/UP 10A Interruptor de la luz de marcha atrás
LAMP
ECU 10A ECM, sensor de flujo de aire en masa (Diesel), módulo de control de la llave smart
1 Relé del elevalunas eléctrico, tablero de instrumentos, motor del techo solar,
IG2 IG2 10A interruptor del dispositivo de nivelación de los faros, faro IZQ/DCH
2 Módulo de control del aire acondicionado, BCM, módulo de control de la llave inteligente,
IG2 IG2 10A unidad de control del limpiaparabrisas
HAZARD 15A Relé de emergencia, interruptor de emergencia
1PDM 25A Módulo de control de la llave Smart
SUNROOF 15A Motor techo solar
2PDM 10A PDM, módulo de control llave smart, interruptor de botón de parada/inicio
TCU 15A TCM (diesel), generador de impulsos 'A'/'B', sensor de velocidad del vehículo,
interruptor de margen del semieje
2
IG1 IG1 10A Sensor de partículas
7 82
