Entretien
Sous-panneau de fusibles du compartiment du moteur
DescriptionCapacité du Composant protégé
fusible
B+ 50A Fusible (EMS 30 A, ECU1 10 A, POMPE CARB 20 A)
EMS 30A Relais de commande du moteur
F/PUMP 20A Relais pompe carb
G4KFECM, TCM
ECU 1 10A
G6DJECM, TCM, boîte comm injecteur
G4KFRelais pompe carb, injecteur nos 1, 2, 3, 4
INJECTOR15A
G6DJRelais pompe carb, relais pompe carburant (bas), ECM
G4KFBobine allum nos 1, 2, 3, 4, condensateur
IGN COIL20A
G6DJBobine allum nos 1, 2, 3, 4, 5, 6, condensateur nos 1, 2
G4KFECM
ECU 2 20A
G6DJBoîte comm injecteur
G4KFRelais ventilateur climat (haut)/(bas), capteur oxygène (sup/inf)
SENSOR 110A
G6DJRelais ventilateur climat (haut)/(bas), ECM, capteur oxygène nos 1, 2, 3, 4
Capteur position arbre cames nos 1, 2, électrovanne comm distance, module antidémarrage,
G4KFsoupape fermeture absorbeur vapeurs, électrovanne comm purge, capteur position vilebrequin,
SENSOR 215A vanne commande d’huile nos 1, 2
G6DJECM, vanne commande huile no 1, 2, 3, 4 électrovanne comm purge, module antidémarrage,
soupape fermeture absorbeur vapeurs
775
