Warning Lights Headlight high beam - BLUEDifferential lock - RED Illuminates when the headlights Illuminates whenever the are switched to main beam.differential is locked. Direction indicators - GREEN While carrying out maintenance operations on The left or right warning light your vehicle, it may be necessary for the dealer flashes in time with the to lock the differential between the front and corresponding left or right rear axles. This will cause the warning light to direction indicator lights whenever they are illuminate. operated. If the warning light fails to flash, or The dealer should always unlock the differential flashes very rapidly, this may indicate a bulb before returning the vehicle to the owner. failure in one of the direction indicator lights. However, if the light illuminates when the If the hazard switch is pressed, both warning starter switch is turned on, this indicates that lights will flash in conjunction with the direction this has not been done. The vehicle should not indicator lights. be driven in this condition because ABS performance will be impaired and Traction Trailer direction indicators - GREENControl will be disabled. Contact your dealer The light illuminates briefly as a immediately and ask for the differential to be bulb check when the starter switch unlocked. is turned to position ‘II’. If a trailer Battery charging - RED is attached, the light illuminates in conjunction The light illuminates as a bulb with the vehicle direction indicator lights to check when the starter switch show that all trailer indicator lights are is turned to position ‘II’ and functioning correctly. In the event of a bulb extinguishes once the engine is running. If it failure on the trailer, the warning light remains remains on, or illuminates whilst driving, a fault off. is indicated. Seek qualified assistance urgently. Seat belt - RED Off Road - AMBER* The light illuminates when the Illuminates briefly as a bulb and starter switch is turned to position system check when the starter ‘II’ and extinguishes after switch is turned to position ‘II’ and approximately 6 seconds, even if the driver's then extinguishes. seat belt remains unfastened. In some markets illumination of the light will be accompanied by If the off-road switch is pressed: a warning chime (see ‘AUDIBLE WARNINGS’, The light flashes continually while the rear of page 53) the vehicle is either; rising to off-road height, or returning to standard ride height. The light illuminates constantly while the suspension remains at off-road height. In addition, the light will flash if extended mode is induced. 50
