text version of content this owner's manual page
from owners manual to the vehicle Mini Cooper, year of production 1961 - 2000:
INFORMATION
Refer to the appropriate section heading for component torque figures, e.g.
Roadwheelnuts-refertoSUSPENSION,
Exhaust front pipe to manifold - refer to MANIFOLD AND EXHAUST
GENERAL
Bolt M6 .10Nm
Bolt M8 .25Nm
Bolt M10 45Nm
Bolt M12 80Nm
1/4 UNC/UNF 9Nm
5/16 UNC/UNF .25Nm
3/8 UNC/UNF 40Nm
7/16 UNC/UNF .75Nm
1/2 UNC/UNF 90Nm
5/8 UNC/UNF 135Nm
ENGINE
Timing gear cover bolts .16 Nm
Timing gear nuts 90 Nm
Timing chain tensioner bolts .22 Nm
Cylinder head nuts .34 Nm then a further 34 Nm
Front cover plate bolts 11 Nm
Rocker shaft nuts 25 Nm
Camshaftthrust plate screws 11 Nm
Rocker cover bolts .5 Nm
Crankshaft pulley bolt 150 Nm
Engine LH mounting:
Mounting to subframe - nuts 25 Nm
Mounting to engine - bolts 25 Nm
Engine RH mounting:
Mounting to flywheel housing cover - bolts .18 Nm
Mounting to subframe - nuts 22 Nm
Engine steady bar upper bolts 22 Nm
Engine steady bar lower:
Bar to subframe bolt 40 Nm
Bar to flywheel housing bolt .40 Nm
Oil pressure gauge sensor 60 Nm
Oil pressure relief valve cap .60 Nm
Oil pressure switch 25 Nm
Oil pump to engine - bolts .11 Nm
Flywheel housing to engine/gearbox - bolts .25 Nm
Earth lead to engine - bolt .10 Nm
Engine to gearbox - nuts and bolts 8 Nm
Flywheel to crankshaft - bolt .150 Nm
Flywheel housing cover - bolts .10 Nm
Engine mounting adaptor plate to engine - bolts 25 Nm
REVISED:12/96 TORQUEWRENCHSETTINGS 1
