HILUX_OM_OM71216L_(EL).book Page 413 Friday, May 9, 2014 7:21 PM
6-3. Manutenzione “fai da te”413
Fusibile Ampe- Circuito
raggio
8 PWR SEAT 30 A Sedile a regolazione elettrica
9 PTC NO.2 50 A Riscaldamento elettrico
1
10 RR CLR* 40 A Nessun circuito
H-LP CLN*2 40 A Lavafari
11 FR HTR 50 A Impianto dell’aria condizionata, A/C
12 ABS NO.2 30 A ABS, TRC, VSC
13 ABS NO.1 40 A ABS, TRC, VSC
Impianto di ricarica, PWR SEAT, RR CLR,
14 ALT 100 A H-LP CLN, FR HTR, AM1, IG1, PTC NO.1,
PTC NO.2, PWR OUT, STOP, TAIL, OBD
15 GLOW 80 A Sistema di candelette ad incandescenza
motore
16 BATT P/I 50 A FOG, HORN, EFI
17 AM2 30 A Motorino di avviamento, ST, IGN, INJ, MET
18 MAIN 40 A H-LP RH, H-LP LH, H-LP RL, H-LP LL
19 A/PUMP 50 A Sistema di controllo delle emissioni
20 H-LP RL 15 A Faro destro (anabbagliante) 6
21 H-LP LL 15 A Faro sinistro (anabbagliante)
22 H-LP RH 15 A Faro destro (abbagliante), faro destro (anab-Manut
bagliante) enzione e
23 H-LP LH 15 A Faro sinistro (abbagliante), faro sinistro
(anabbagliante)
c
Sistema d’iniezione di carburante multipoint/u
24 EFI No.2 10 A sistema d’iniezione di carburante multipointra
sequenziale
25 ECU-IG-NO.2 10 A Impianto di ricarica, impianto dell’aria condi-
zionata, ABS, VSC, lavafari
HILUX_OM_OM71216L_(EL)
