Attaching jumper cables 1. Switch off the ignition in both vehicles ⇒ Starting and stopping the engine. 2. Open the battery cover in the engine compartment if the battery has a cover ⇒ Vehicle battery. 3. Attach one end of the red jumper cable to the positive terminal (+) of the dead battery: (1) ⇒ . 4. Attach the other end of the red jumper cable to the positive terminal (+) of the good battery (booster battery): (2). 5. Attach one end of the black jumper cable to the negative terminal (-) of the booster battery: (2) ⇒ fig. 199. 6. Attach the other end of the black jumper cable (3) to a bare metal part of the vehicle with the dead battery. This part should be connected directly to the engine block. You may also attach the cable to the engine block itself or to the towing eye installed on the front of the vehicle ⇒ page 405, Towing. Attach the clamp to a point that is as far away as possible from the dead battery (1) ⇒ . On vehicles with a 1.8 liter engine, see ⇒ fig. 198 (-). 7. Route the jumper cables so that they cannot get caught in any moving parts in the engine com- partment of either vehicle. Starting the engine x Start the engine of the vehicle with the good battery that is providing help and let it run at idle speed. x Turn on the ignition of the vehicle with the dead battery. If the engine starts, wait 2 to 3 minutes until it “runs smoothly” before removing the jumper cables as described below ⇒ . If the engine does not start within about 10 seconds, turn off the ignition and wait at least 1 minute; then try again. Before removing the jumper cables x Switch off the headlights (if they are on). x In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the cables are disconnected. Removing jumper cables With the engine running, remove the jumper cables in reverse order to the way they were connected. 1. Disconnect the black (-) cable from the vehicle with the dead battery. 2. Disconnect the black (-) cable from the other vehicle (vehicle with the good battery). 3. Disconnect the red (+) cable from the other vehicle (vehicle with the good battery). 4. Disconnect the red (+) cable from the vehicle with the dead battery. 5. Close the battery cover. 6. If necessary, unscrew the towing eye on the front of the vehicle ⇒ Installing the front towing eye.
