text version of content this owner's manual page from owners manual to the vehicle Jeep Patriot, year of production 2006:
MAINTAINING YOUR VEHICLE 395
Cavity CartridgeMini- Description Cavity CartridgeMini- Description
Fuse Fuse Fuse Fuse
13 20 Amp Pwr Run/Acc Outlet 20 15 Amp IOD Feed Radio
Yellow RR/Dome Lamp Lt Blue
14 10 Amp IOD CCN 21 10 Amp IOD Feed Intrus
Red Red Mod/Siren (If
15 40 Amp RADFanRelay Bat- Equipped)
Green tery Feed 22 10 Amp IGN RUN Heat/AC/
16 15 Amp IGN Run/Acc Dome Red Compass Sensor
Lt Blue Lamp/Sunroof/Rear 23 15 Amp ENGASDRelayFeed
Wiper Motor/ACC Lt Blue 3
Inverter 24 15 Amp Power Sunroof Feed
17 10 Amp IOD Feed Mod-Wcm Lt Blue 7
Red 25 10 Amp Heated Mirror (If
18 40 Amp ASDRelay Contact Red Equipped)
Green PWRFeed 26 15 Amp ENGASDRelayFeed
19 20 Amp PWRAmp1&Amp Lt Blue 2
Yellow 2 Feed 27 10 Amp IGN RUN Only ORC
Red Feed
