TA eng 7:YF eng 7.qxd 17-05-2011 16:41 Side 61
Vedligeholdelse
Sikringspanel i motorrum (kun ved HID-forlygter)
SymbolAmpereværdi Beskyttet komponent
10 A PCB-sikrings- og relæboks (A/C-relæ)
20 A PCB-sikrings- og relæboks (forlygter (nær) relæ)
15 A PCB-sikrings- og relæboks (brændstofpumpe #1 relæ)
10 A PCB-sikrings- og relæboks (hornrelæ, hornrelæ til tyverialarm)
15 A B3LA: PCB-sikrings- og relæboks (brændstofpumpe #2 relæ)
10 A PCB-sikrings- og relæboks (forlygter (fjern) relæ)
15 A PCB-sikrings- og relæboks (motorkontrolrelæ, brændstofpumpe #1 relæ, brændstofpumpe #2
relæ (F3LA)), indsprøjtning #1/#2/#3 (B3LA), PCM
FUSE 10 A B3LA: PCM, PCB-sikrings- og relæboks (motorkontrolrelæ)
(HID-forlygter) 10 A TCM, gearkassekontakt, lygte i bageste kofanger, instrumentgruppe, BCM, baklygte
venstre/højre, baklygtekontakt
10 A ECM, forrudeviskermotor, multifunktionskontakt
10 A HID-forlygte venstre
10 A ECM/TCM/PCM, PCB-sikrings- og relæboks (motorkontrolrelæ)
10 A HID-forlygte højre
PCB-sikrings- og relæboks (motorkontrolrelæ, A/C-relæ, A/C-relæ, ventilatorrelæ, startrelæ),
10 A ECM/PCM, udluftningsstyreventil, oliereguleringsventil #1, oliereguleringsventil #2 (uden F3LA),
positionsføler #1 til knastaksel, positionsføler #2 til knastaksel (uden F3LA), magnetventil til
variabel indsugning (B3LA)
7 61
