text version of content this owner's manual page from owners manual to the vehicle Subaru Outback, year of production 2004 - 2009:

Maintenance and service 11-23 Automatic transmission fluid &Checking the fluid level The automatic transmission fluid expands largely as its temperature rises; the fluid level differs according to fluid temperature. Therefore, there are two different scales for checking the level of hot fluid and cold fluid on the dipstick. Though the fluid level can be checked without warming up the fluid on the “COLD” range, we recommend checking the fluid level when the fluid is at operating4-speed automatic transmission1)HOTrange temperature. 1)Yellow handle 2)COLDrange 3)Upper level ! Checking the fluid level when the 4)Lower level fluid is hot Check the fluid level monthly. 4. Pull out the dipstick and check the fluid 1. Drive the vehicle several miles to raise level on the gauge. If it is below the lower the temperature of the transmission fluid level on the “HOT” range, add the recom- up to normal operating temperature; 158 mendedautomatictransmissionfluid up to to 1768F (70 to 808C) is normal. the upper level. 2. Parkthevehicle on a level surface and ! Checking the fluid level when the set the parking brake. fluid is cold 3. First shift the selector lever in each When the fluid level has to be checked position. Then shift it in the “P” position, without time to warm up the automatic and run the engine at idling speed. transmission, check to see that the fluid 5-speed automatic transmissionlevel is between the lower level and upper 1)Yellow handle level on the “COLD” range. If it is below that range, add fluid up to the upper level. Be careful not to overfill. – CONTINUED –
