Instrumentation/Driver Information Body & Accessories
Configuring Instrument Cluster
• When replacing the instrument cluster, the new cluster has to be configured. To do this,
connect the WDS to the vehicle and select the option Toolbox→Module
Programming→Programmable Module Installation→IC. During this procedure the
mileage is uploaded into the new instrument cluster.
NOTE: Configuring of the instrument cluster can only be conducted once. The new module
must display less than 100 km for the mileage data to be uploaded. If a module with
more than 100 km is configured, WDS will display an error message after configuring
and indicate that the procedure failed. In this situation, all data other than the mileage
will have been uploaded into the new instrument cluster, so the configuration is
actually successful.
09-108 Service Training Mazda5
