HILUX_OM_OM0K287E_(EE).book Page 319 Tuesday, April 26, 2016 11:00 AM
4-5. Using the driving support systems319
Using the rear view monitor system
■ Screen description
X Vehicles without smart entry & start system
The rear view monitor system screen will be displayed if the shift
lever is shifted to R while the engine switch is in the “ON” position.
X Vehicles with smart entry & start system
The rear view monitor system screen will be displayed if the shift
lever is shifted to R while the engine switch is in IGNITION ON
mode.
4
D
r
iv
in
1 Vehicle width guide line g
The line indicates a guide path when the vehicle is being backed straight
up.
The displayed width is wider than the actual vehicle width.
2 Vehicle center guide line
The line indicates the estimated vehicle center on the ground.
3 Distance guide line (red)
The line shows distance behind the vehicle, a point approximately 0.5 m
(1.5 ft.) from the edge of the bumper.
4 Distance guide line (blue)
The line shows distance behind the vehicle, a point approximately 1 m
(3 ft.) from the edge of the bumper.
HILUX_OM_OM0K287E_(EE)
