text version of content this owner's manual page from owners manual to the vehicle VW Golf VI, year of production 2008 - 2013:
Maximum power Injection Engine Maximum torque (SAE net) No. of cylinders
output (SAE net) technology ID Displacement
code
170 hp at 5700 rpm CBTA 177 lb-ft at 4250 rpm 5 cylinders
(125 kW at CBUA (240 Nm at 4250 rpm) 151 CID
5700 rpm) 2.5L (2480 ccm)
256 hp at 6000 rpm CRZA 243 lb-ft at 2,400 – 5,200 rpm 4 cylinders
(188 kW at TSI® 121 CID
6000 rpm) 2.0L (330 Nm at 2400 – 5200 rpm) (1984 ccm)
Diesel engines
Maximum power Injection Engine Maximum torque No. of cylinders
output (SAE net) technology code Displacement
140 hp at 4,000 rpm TDI® CJAA236 lb-ft at 1750 rpm 4 cylinders
(103 kW at 4,000 rpm 2.0L (320 Nm at 1750 rpm) 120 CID
with DPF) (1968 ccm)
Dimensions
¤ Please first read and note the introductory information and heed the WARNINGS
Length 165.3 – 169.6 inches (4199 – 4308 mm)
Width 70.3 inches (1786 mm)
Height (unloaded) 57.5 – 60.3 inches (1461 – 1532 mm)
Wheelbase 101.4 inches (2575 mm)
4
Minimum turning circle diameter (wall to wall) about 35 feet 9 inches (10.9 m)
4
Track , front 60.1 – 60.7 inches (1527 – 1541 mm)
4
Track , rear 59.1 – 60.0 inches (1500 – 1523 mm)
Ground clearance (unloaded) about 5.2 – 5.9 inches (132 – 150 mm)
NOTICE
x Please be careful when parking your vehicle in areas with parking barriers or cubs. rThese
vary in height and could damage your bumper and related parts if the front of your vehicle hits
a barrier or curb that is too high while you are getting into or out of a parking spot.
x Always be careful when you enter a drivewa oyr drive up or down steep ramps or over
curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as
bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).
4
Slight differences to these figures are possible, depending on wheel and
tire size fitted and the level selected.
