from owners manual to the vehicle VW Passat, year of production 2010 - 2014:
Model Engine Tire dimensions Tire
pressure
PSI / kPa
215/60 R 16 30 / 210
2.0 l / 140 hp (103 kW) 215/55 R 17 32 / 220
235/45 R 18 33 / 230
215/60 R 16 29 / 200
Passat 2.5 l / 170 hp (125 kW) 215/55 R 17 30 / 210
235/45 R 18 30 / 210
215/55 R 17 33 / 230
3.6 l / 280 hp (206 kW)
235/45 R 18 35 / 240
Compact spare wheel 135/90 R 16 60 / 420
The Tire Pressure Monitoring System is configured at the factory with the correct tire inflation
pressure applicable for the vehicle model, engine and factory-installed tires. The tire inflation
pressure is listed on the tire inflation pressure label on the driver door jamb. The tire inflation
pressures for the road tires are listed on this label. The inflation pressure for the compact spare is as
specified on the tire pressure label or on a separate label for the compact spare, if there is one. In
the event of a discrepancy between the above figures and the tire pressures listed on the tire
inflation pressure label, the pressures listed on the label are the ones you should use. The listed
pressure applies to all road tires. The Tire Pressure Monitoring System must be recalibrated using
the SET button whenever you remove and remount or change any wheel or tire on the vehicle, even
if the reinstalled or replacement wheels and tires are identical to those that were removed and even
if the tire pressure does not change.
Applicable only in the United States and Canada
Tread depth and tread wear indicators
Fig. 180 Tread pattern: Wear indicator.
¤ Please first read and note the introductory information and heed the WARNINGS .
Tread depth
Most driving situations require as much tread depth as possible and similar tread depth for the tires on
the front and rear wheels. This is especially true when driving in winter weather, at low temperatures
and under wet conditions ⇒ .
