owners manual Volvo XC60

all ratings: 0 average rating: 5

07 During your trip Cargo area Steel cargo grid* Installing the steel cargo grid Installing the cover For information about the necessary tools 1. Press the end piece on one side of the and procedures for installing/removing the cargo area cover into the retaining steel cargo grid, please refer to the assembly bracket in the side panel of the cargo 1 instructions that were included when the grid area . was purchased. 2. Do the same on the opposite side . 3. Press both sides of the cover until they Cargo area cover* click into place . The red mark will no longer be visible. 4. Check that both ends of the cover are G031978 securely locked in place. Removing the cover Your vehicle can be equipped with a steel 1. Press one of the end pieces of the cover grid that helps prevent objects in the cargo inward. area from moving forward into the passenger compartment. 2. Pull the cover carefully upward and out- ward. The other end will release automati- Folding the grid up/down G031977 cally from its retaining bracket. Grasp the lowering edge of the grid and pull it rearward/upward, or push it downward/ Folding down the cargo area cover's forward. Use rear flap • Pull the cover over the cargo and hook it The cargo area cover's rear flap points hori- into the holes in the rear cargo area pil- NOTE 07 zontally when the cover is retracted (rolled lars. up). To fold it down: If the steel grid is to be used with the • To retract (roll up) the cover, release it optional cargo area cover, the grid must – Pull the flap slightly rearward past its sup- from the holes and guide it toward the be folded down before the cargo area ports and fold it down. cover is put in place. rear seat backrest. 1 Assembly instruction no. 30715972. * Option/accessory, for more information, see Introduction. 287
