text version of content this owner's manual page from owners manual to the vehicle Alfa Romeo 147, year of production 2000 - 2010:

258-277_Alfa147 Q2 GB 4-07-2008 12:06 Pagina 265 Maximum speed index Maximum speed index CORRECT RIM READING Q = up to 160 km/h. for snow tyres Below, please find the instructions need-TIONS R = up to 170 km/h Q M +S = up to 160 km/h. ed to understand the meaning of the code T M +S = up to 190 km/h. stamped on the rim, as shown in (fig. 5). S = up to 180 km/h. T = up to 190 km/h. H M +S = up to 210 km/h. U = up to 200 km/h. COMPACT SPARE WHEEL Example: H = up to 210 km/h. Pressed steel rim. 6.5 J x 16 H2 ET 43 V = over 210 km/h. Tubeless tyre. ZR = over 240 km/h. For specific markets normally-sized spare TECHNICAL SPECIFICA W = up to 270 km/h. wheel. 6.5 = rim width in inches (1) Y = up to 300 km/h. J = rim drop centre outline (side pro- jection where the tyre bead rests) (2) 16 = rim nominal diameter in inches (corresponds to diameter of the tyre to be mounted) (3=ø) H2 = “hump” shape and number (relief on the circumference holding the Tubeless tyre bead on the rim). ET 43 = camber angle (distance between disk/rim line and wheel rim cen- tre line) 265
