owners manual Seat Leon

all ratings: 0 average rating: 5

leon_EN.book Seite 252 Donnerstag, 15. April 2010 9:19 09 252 If and when Fuse cover underneath the steering wheel The electric windows are protected by circuit breakers. These reset automat- – Switch off the ignition and the component concerned.ically after a few seconds when the overload (caused for example by frozen windows) has been corrected. – Identify the fuse corresponding to the damaged electric Fuses colour code consumer ⇒page254. – Take the plastic clip from inside the fuse cover, fit it onto the Colour Amps blown fuse and pull the fuse out. light brown 5 Red 10 – Replace the blown fuse (which will have a melted metal strip) Blue 15 with a new fuse of the same ampere rating. Yellow 20 Fuse cover in engine compartment Natural (white) 25 – Switch off the ignition and its failed electrical component.Green 30 – Prise off the fuse cover in the engine compartment by pressing orange 40 the tabs towards the centre of the cover ⇒ page 251, fig. 161.Red 50 – Identify the fuse for the failed component ⇒ page 254. white 80 – Take the plastic clip from inside the fuse cover (at left-hand end Blue 100 of the dash panel), fit it onto the blown fuse and pull the fuse out.grey 150 – Replace the blown fuse (which will have a melted metal strip) violet 200 with a new fuse of the same ampere rating. WARNING – Carefully fit the fuse cover back on to ensure no water can enter Never “repair” damaged fuses and never replace them with fuses with a the fuse box. higher rating. Failure to comply could result in fire. This could also cause damage to other parts of the electrical system. The individual electrical circuits are protected by fuses. The fuses are located behind a cover at the left-hand end of the dash panel and on the left-hand side of the engine compartment. Note • If a newly replaced fuse blows again after a short time, the electrical system must be checked by a qualified workshop as soon as possible.
